RoTec Polska Sp. z o.o.
- ul. Strefowa 8A, 43-100 TYCHY, Poland
- +48 327806750
- www.rotec.pl
Description
RoTec Polska is the exclusive representative of Schenck RoTec GmbH (manufacturer of balancing machines), Ecoclean GmbH (manufacturer of industrial cleaning machines) and DATRON AG (manufacturer of precise CNC milling machines) in Poland. It also acts as a distributor of Ultratecno ultrasonic cleaning machines and Cryonomic dry ice blasters. It offers professional services in the sphere of consultancy and sales of balancing and cleaning machines, comprehensive service, spare parts sales, modernization of second-hand machines, inspections - certifications of machines, balancing and cleaning services, trainings, consulting and presentation of machines in its sales showroom.
Products
CNC milling machine DATRON Neo
CNC milling machine DATRON Neo
The CNC milling machine Neo from the German company Datron is an ideal combination of small, compact dimensions with a relatively large working area. Its ergonomic design and easy access from the front facilitate quick and reliable clamping and machining of the workpiece. Additionally, the vacuum table ensures stability during operation. The machine also impresses with its excellent machining speed (feed speed 28 m/min) thanks to the power of 2 kW and a spindle speed reaching 40,000 rpm. Thanks to the use of alcohol cooling, the machining process is not only effective, but also clean. The modern interface with a touch screen makes operation simple and intuitive, like operating a smartphone. The Datron Neo milling machine is not only a tool, it is also a guarantee of efficiency and quality in the processing of workpieces.
Machining table: Portal construction, mineral-cast machine bed, aluminium table, steel stand
Traverse path (X x Y x Z): 520 mm x 420 mm x 220 mm
Working area (X x Y): 500 mm x 400 mm x 175 mm
Portal passage: 175 mm
Installation dimensions without operating terminal (W x D x H): 805 mm x 1,290 mm x 1,880 mm
Control system/software DATRON next
Operating terminal 24” multi-touch screen
User-friendly hand-held control unit P
Drive system Brushless digital servo drives; directly driven ball-screw spindle drives for each axis
Rotary axis (4th axis) Optional
Machining spindle 2.0 kW HF spindle; up to 40,000 rpm, direct shank
Tool magazine with length sensor 24 stations with direct-shank tool holding fixture
3D measuring probe P
Feed Up to 18 m/min / Up to 28 m/min
Positioning feed Up to 18 m/min / Up to 28 m/min
Weight Approx. 700 kg
Traverse path (X x Y x Z): 520 mm x 420 mm x 220 mm
Working area (X x Y): 500 mm x 400 mm x 175 mm
Portal passage: 175 mm
Installation dimensions without operating terminal (W x D x H): 805 mm x 1,290 mm x 1,880 mm
Control system/software DATRON next
Operating terminal 24” multi-touch screen
User-friendly hand-held control unit P
Drive system Brushless digital servo drives; directly driven ball-screw spindle drives for each axis
Rotary axis (4th axis) Optional
Machining spindle 2.0 kW HF spindle; up to 40,000 rpm, direct shank
Tool magazine with length sensor 24 stations with direct-shank tool holding fixture
3D measuring probe P
Feed Up to 18 m/min / Up to 28 m/min
Positioning feed Up to 18 m/min / Up to 28 m/min
Weight Approx. 700 kg
Ultrasonic cleaning machine Ultratecno ACM-500N
Ultrasonic cleaning machine Ultratecno ACM-500N
The ACM-500N ultrasonic cleaner from the Spanish company Ultratecno is designed for washing various parts in the production and regeneration process, such as cylinder heads, pistons, engine blocks, coolers, pumps, injection molds, heat exchangers, etc.
The device provides the highest quality and power of washing thanks to the following advantages:
- 28kHz ultrasound frequency ensures stronger action and therefore the best results in the case of difficult to remove contaminants
- digitally synchronized ultrasound generators increase the effectiveness of cavitation and help to avoid formation of the so-called 'Hot spots'
- the lift platform facilitates loading and unloading of parts and enhances the cleaning effect
- special thermal and acoustic insulation ensures low energy losses
Capacity: 546 l
Max lift load: 350 kg
Ultrasound frequency: 28 kHz
Ultrasound power: 4 kW
Loading tray dimensions: 1150 x 525 mm
Integrated oil separator
Max lift load: 350 kg
Ultrasound frequency: 28 kHz
Ultrasound power: 4 kW
Loading tray dimensions: 1150 x 525 mm
Integrated oil separator
Solvent industrial cleaning machine ECOCLEAN EcoCcore
Solvent industrial cleaning machine ECOCLEAN EcoCcore
EcoCcore is an extremely efficient, and at the same time accurate, single-chamber cleaning machine that uses modified alcohols and non-halogenated hydrocarbons. The device offers the highest quality and efficiency of cleaning thanks to the larger size of the working chamber. Thanks to modular design, the possibility of equipping it with 2 or 3 tanks, EcoCcore can be easily adapted to individual customer requirements. Importantly, the highest efficiency and quality of cleaning go hand in hand here with the extremely simple and friendly operation of the machine and a very attractive design.
▪ Flexible load composition of:
1 x basket 670 x 480 x 400 or
4 x baskets, each basket 480 x 320 x 200 mm
▪ 200 kg load weight
▪ High-performance, continuous distillation for reconditioning of the cleaning medium
▪ Highly-effective filtration which can be adapted to individual requirements
▪ Automated oil discharge to reduce system downtime
▪ Industrial grade Siemens control panel with a high resolution, 7-inch color display and a touch screen for simple, fast and safe operation
1 x basket 670 x 480 x 400 or
4 x baskets, each basket 480 x 320 x 200 mm
▪ 200 kg load weight
▪ High-performance, continuous distillation for reconditioning of the cleaning medium
▪ Highly-effective filtration which can be adapted to individual requirements
▪ Automated oil discharge to reduce system downtime
▪ Industrial grade Siemens control panel with a high resolution, 7-inch color display and a touch screen for simple, fast and safe operation
SCHENCK Smart Balancer 4 for field balancing and vibration diagnostics
SCHENCK Smart Balancer 4 for field balancing and vibration diagnostics
The Smart Balancer 4 is the latest version of the innovative device for field balancing and vibration diagnostics from the German leader SCHENCK RoTec. With advanced measurement and diagnostic functions, the ability to perform measurements simultaneously in up to 6 channels and real-time data monitoring, the Smart Balancer 4 provides fast and precise balancing, eliminating vibrations. The intuitive user interface on the 10-inch touch screen and automation and data archiving functions make it easy to use, even for less experienced operators. Smart Balancer 4 increases the efficiency and quality of work and allows you to minimize maintenance costs and prevent failures thanks to early detection of component wear.
Dialogue-assisted operator guidance, vector display of the oscillation quantities, and PDF of balancing reports as well as archiving via PC
Balancing speed: 120 to 80,000 rpm
Number of correction planes: 1 or 2
Special features:
- Up to 6 input channels.
- Simultaneous Overall and FFT spectrum while balancing
- Unbalance correction at fixed locations
Measuring Channels
2 channels for Standard configuration
6 channels when upgraded to Multi-Channel configuration
2 channels for optical laser reference sensor
Features Overview:
Balancing in 1 or 2 planes
Vibration acceleration, velocity, displacement, speed, voltage (AC/DC)
Signals: Spectrum (amplitude, envelope), time wave form, Phase Measurement (0.5 – 5th order), Cross channel Phase
Advanced analysis package
Balancing speed: 120 to 80,000 rpm
Number of correction planes: 1 or 2
Special features:
- Up to 6 input channels.
- Simultaneous Overall and FFT spectrum while balancing
- Unbalance correction at fixed locations
Measuring Channels
2 channels for Standard configuration
6 channels when upgraded to Multi-Channel configuration
2 channels for optical laser reference sensor
Features Overview:
Balancing in 1 or 2 planes
Vibration acceleration, velocity, displacement, speed, voltage (AC/DC)
Signals: Spectrum (amplitude, envelope), time wave form, Phase Measurement (0.5 – 5th order), Cross channel Phase
Advanced analysis package
Dry ice blaster Cryonomic COMBI73R
Dry ice blaster Cryonomic COMBI73R
COMBI73 from the Belgian company Cryonomic is an efficient and economical machine for dry ice blasting. Thanks to the patented solutions of feeding and distributing dry ice, Cryonomic machines provide approx. 20% less dry ice consumption compared to the competition. The machine feeds dry ice and compressed air in one hose, which ensures low air consumption and greater convenience of use. These machines are distinguished by good ergonomics, ease of use and service, and reliability.
Max. cleaning pressure: 16 bar
Dry ice hopper capacity: 30 kg
Dry ice flow rate: 25 - 100 kg
Remote control of pressure and dry ice consumption on the gun
Optional cleaning with abrasive
Dry ice hopper capacity: 30 kg
Dry ice flow rate: 25 - 100 kg
Remote control of pressure and dry ice consumption on the gun
Optional cleaning with abrasive
Business sector
Control and measuring instruments
Services, repairs, maintenance and modernisation, second-hand machines
